The UME1E220MDD1TP is an aluminum electrolytic capacitor manufactured by Nichicon. Part of the UME series, it is designed for general-purpose applications requiring a reliable and compact energy storage solution. These capacitors are commonly used in a variety of electronic circuits to filter, decouple, and store energy.

Applications:

• Power Supplies: Smoothing ripple current and providing stable voltage output.
• Consumer Electronics: Used in audio equipment, televisions, and other devices for filtering and decoupling.
• Industrial Equipment: Employed in various control systems and power circuits.
• LED Lighting: Providing stable power to LED drivers.
• General-Purpose Electronic Circuits: Used in a wide range of circuits for energy storage and filtering.

Features:

• Aluminum Electrolytic Construction: Offers a good balance of performance, cost, and size.
• Radial Lead Type: Suitable for through-hole mounting on printed circuit boards.
• Compact Size: Allows for use in space-constrained applications.
• Wide Operating Temperature Range: Ensures reliable operation in diverse environments.
• Long Life: Designed for extended operational life, enhancing system reliability.

Benefits:

• Stable Performance: Provides consistent and reliable performance over its operating life.
• Cost-Effective Solution: Offers a good balance of performance and cost.
• Easy to Mount: Radial lead type simplifies through-hole mounting.
• Compact Design: Suitable for applications where space is limited.
• Extended Lifespan: Enhances the overall reliability and longevity of the electronic device.

Additional Details:

The UME1E220MDD1TP has a capacitance of 22µF and a voltage rating of 25V. It operates within a specified temperature range, typically from -40°C to +85°C. Key electrical characteristics include equivalent series resistance (ESR), impedance, and ripple current rating. ESR affects the capacitor's ability to handle ripple current, with lower ESR values resulting in better performance in high-frequency applications. The ripple current rating indicates the maximum alternating current the capacitor can handle without overheating.

When using the UME1E220MDD1TP, it is essential to adhere to the manufacturer's recommended operating conditions, including voltage, temperature, and ripple current. Exceeding these limits can lead to premature failure or reduced lifespan. Ensure proper polarity during installation, as reverse polarity can damage the capacitor. The capacitor should be stored in a clean, dry environment to prevent corrosion and degradation.
