PMEG4030ER,115 Nexperia USA Inc. PMEG4030ER,115 label picture
Same model may have multiple batches, images only for reference.
PMEG4030ER,115 Nexperia USA Inc. PMEG4030ER,115 label picture
PMEG4030ER,115 Nexperia USA Inc. PMEG4030ER,115 label picture
Same model may have multiple batches, images only for reference.

PMEG4030ER,115

Part No PMEG4030ER,115
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 3A SOD123W
Datasheet
PMEG4030ER,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 540mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 100μA @ 40V
Capacitance @ Vr, F 250pF @ 1V, 1MHz
Mounting SMD (SMT)
Case / Package CFP3
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 1089632-PMEG4030ER,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PMEG4030ER,115 CAD Model

Description

The Nexperia USA Inc. PMEG4030ER,115 is a Schottky diode with a maximum DC reverse voltage of 40V and an average rectified current of 3A.

  • Forward Voltage: 540mV @ 3A
  • Reverse Leakage Current: 100μA @ 40V
  • Capacitance: 250pF @ 1V, 1MHz
  • Speed: 200mA (Io)
  • Mounting: Surface mount device (SMD)
  • Package: CFP3
  • Win Source Part Number: 1089632
  • Designed for: Discrete semiconductor applications
