SF2094B RF Monolithics, Inc
Same model may have multiple batches, images only for reference.

SF2094B

Part No SF2094B
Manufacturer Murata Electronics North America
Catalog SAW Filters
Description FILTER SAW 380MHZ 10SMD
Datasheet
SF2094B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - SAW Filters
Mfr Murata Electronics North America
Package Tape & Reel
Product Status Obsolete
Frequency - Center 380MHz
Bandwidth 4MHz
Insertion Loss 13.5dB
Applications WiMax
Mounting Type Surface Mount
Package / Case 10-SMD, No Lead
Height (Max) 0.079" (2.00mm)
Size / Dimension 0.276" L x 0.197" W (7.00mm x 5.00mm)
Base Product Number SF20
Standard Package 2,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8541.60.0080
Win Source Part Number 665180-SF2094B
Ultra Librarian 3D Model Ultra Librarian SF2094B CAD Model

Description

The SF2094B is a surface mount SAW filter designed for WiMax applications.

  • Mounting Type: Surface Mount
  • Application: WiMax
  • Package: 10-SMD, no lead
  • Dimensions: 0.276" (Length) x 0.197" (Width) x 0.079" (Height)
  • Insertion Loss: 13.5dB
  • Center Frequency: 380MHz
  • Bandwidth: 4MHz
  • Manufacturer: Murata Electronics North America
  • Status: Obsolete
  • Package Quantity: 2,000 pieces (Tape and Reel)
