MP9950DQ-LF-Z Monolithic Power Systems Inc.
Same model may have multiple batches, images only for reference.

MP9950DQ-LF-Z

Part No MP9950DQ-LF-Z
Manufacturer Monolithic Power Systems Inc.
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC PWR SWITCH N-CHANNEL 1:1
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Monolithic Power Systems Inc.
Packaging Reel
Switch Type General Purpose
Number of Outputs 1
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Voltage - Load 3V ~ 15V
Voltage - Supply (Vcc/Vdd) Not Required
Current - Output (Maximum) 5A
Rds On (Typ) 40mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO
Temperature Range - Operating -40°C ~ 125°C
Manufacturer Pack Quantity 5,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 804512-MP9950DQ-LF-Z
Ultra Librarian 3D Model Ultra Librarian MP9950DQ-LF-Z CAD Model

Description

The Monolithic Power Systems Inc. MP9950DQ-LF-Z is a general-purpose N-channel MOSFET switch.

  • Voltage Load: 3V ~ 15V
  • Output Configuration: High Side
  • Current Output: 5A
  • Standard Package: 5000
  • Supply and Demand Status: Balanced
  • Temperature Range: -40°C ~ 125°C
  • Packaging: Reel
