87758-1616 Real Image
Same model may have multiple batches, images only for reference.

87758-1616

Part No 87758-1616
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Unshrouded Header HDR 16 POS 2mm Solder ST Top Entry Thru-Hole Milli-Grid™ Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Gender Male
Contact Material Brass
Contact Plating Gold
Country of Origin SG
Current Rating 2 A
Depth 4 mm
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 5.5 mm
Housing Color Black
Housing Material Nylon
Lead Pitch 2 mm
Length 15.9 mm
Max Current Rating 2 A
Max Operating Temperature 105 °C
Max Voltage Rating (AC) 125 V
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 16
Number of Contacts 16
Number of Pins 16
Number of Positions 16
Number of Rows 2
Orientation Vertical
Pitch 2 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Row Spacing 2 mm
Termination Solder
Voltage Rating 125 V
Voltage Rating (DC) 125 V
Win Source Part Number 1149077-87758-1616
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 87758-1616 CAD Model

Description

The Molex, LLC electronic component is a male connector with 16 contacts.

  • Gender: Male
  • Contacts: 16
  • Pitch: 2mm
  • Voltage Rating: 125V
  • Current Rating: 2A
  • Housing Material: Nylon
  • Color: Black
  • RoHS Compliant: Yes
  • Popularity: Medium
  • Applications: Circular Connectors and Housings
