87437-0543 Real Image
Same model may have multiple batches, images only for reference.

87437-0543

Part No 87437-0543
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 5 POS 1.5mm Solder RA SMD Automotive T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Beige
Contact Gender Male
Contact Material Brass
Contact Plating Tin
Contact Resistance 40 mΩ
Country of Origin SG
Current Rating 2.5 A
Depth 4.45 mm
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 5.75 mm
Housing Color Beige
Housing Material Nylon
Insulation Resistance 1 GΩ
Lead Free Contains Lead
Lead Pitch 1.5 mm
Length 8.8 mm
Material Nylon
Max Current Rating 3 A
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 350 V
Min Operating Temperature -55 °C
Mount Surface Mount
Number of Circuits 5
Number of Contacts 5
Number of Pins 5
Number of Positions 5
Number of Rows 1
Orientation Vertical
Packaging Cut Tape
Pitch 1.5 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Win Source Part Number 1007476-87437-0543
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 87437-0543 CAD Model

Description

The 1007476-87437-0543 is a male connector with a pitch of 1.5 mm and a number of positions of 5 manufactured by Molex LLC.

  • Pitch: 1.5 mm
  • Positions: 5
  • Voltage Rating: 250 V
  • Current Rating: 2.5 A
  • Contact Material: Brass
  • Termination: Solder
  • Length: 8.8 mm
  • Height: 5.75 mm
  • Housing Material: Nylon
  • Housing Color: Beige
  • Contact Plating: Tin
  • Contact Resistance: 40 mΩ
  • Supply and Demand Status: Shortage
  • Packaging: Cut tape
