The 53261-0571 is a Micro-Latch connector housing manufactured by Molex, LLC. It's designed for wire-to-board connections requiring a compact and reliable solution. This housing is part of the Micro-Latch series, characterized by its small form factor and secure locking feature.

Applications

• Consumer electronics (e.g., laptops, smartphones)
• Industrial automation equipment
• Medical devices
• Telecommunications equipment
• Automotive electronics

Features

• Compact size
• Positive locking mechanism for secure connections
• Durable construction
• Polarization to prevent incorrect mating
• 5 Circuits

Benefits

• Space-saving design allows for use in miniaturized devices.
• Reduces the risk of accidental disconnections in demanding environments.
• Ensures long-term reliability in various operating conditions.
• Prevents damage due to misaligned connections.
• Accommodates multiple signal lines in a single connector.

Technical Specifications

The 53261-0571 is a 5-circuit housing with a 1.25mm pitch. It's typically constructed from UL 94V-0 rated material. Wire gauge support is generally 30 to 26 AWG. The mating connector is a key detail available in the Molex datasheet. Check the datasheet for the specific current and voltage ratings.

Note: Always consult the Molex datasheet for the most accurate and up-to-date specifications, including mating connector information, current ratings, voltage ratings, and proper application guidelines. Ensure compatibility with your specific application requirements for optimal performance and safety.
