43650-0504 Real Image
Same model may have multiple batches, images only for reference.

43650-0504

Part No 43650-0504
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Board to Board PIN 5 POS 3mm Solder RA Thru-Hole Box
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Plating Gold
Country of Origin US
Current Rating 5 A
Fastening Type Ramp
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Compliant
Halogen Free Low Halogen
Housing Color Black
Housing Material Thermoplastic
Lead Free Yes
Lead Pitch 3 mm
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 5
Number of Contacts 5
Number of Positions 5
Number of Rows 1
Orientation Right Angle
Pitch 3 mm
Plating Tin
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 1038659-43650-0504
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 43650-0504 CAD Model

Description

The Molex 1038659-43650-0504 is a 5-position male pin connector with a pitch of 3mm.

  • Positions: 5
  • Gender: Male
  • Pin Type: Pin Connector
  • Pitch: 3mm
  • Number of Rows: Single Row
  • Termination: Solder
  • Fastening Type: Ramp
  • Contact Material: Brass
  • Contact Plating: Gold
  • Current Rating: 5A
  • Voltage Rating: 250V
  • Housing Material: Thermoplastic
  • Housing Color: Black
  • Mounting Type: Through-Hole
  • Orientation: Right Angle
  • RoHS Compliant: Yes
