Part No 34691-0200
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Stac64 Right-Angle Header Assembly, 20 Circuits, Polarization A, Black, Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Rectangular
Contact Material Brass
Contact Plating Tin
Country of Origin CN
Current Rating 10 A
Depth 31.89 mm
Gender Male
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Height 22.05 mm
Housing Material Thermoplastic
Maximum Operating Temperature 100 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 20
Number of Contacts 20
Number of Positions 20
Number of Rows 2
Orientation Right Angle
Pitch 2.54 mm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 500 V
Voltage Rating (DC) 500 V
Width 34.04 mm
Win Source Part Number 1029788-34691-0200
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 34691-0200 CAD Model

Description

This Molex LLC manufactured black rectangular connector is a through-hole type with a right-angle orientation.

  • Orientation: Right-Angle
  • Positions: 20
  • Rows: 2
  • Pitch: 2.54 mm
  • Contact Material: Brass
  • Voltage Rating: 500 V
  • Current Rating: 10 A
  • Housing Material: Thermoplastic
  • Contact Plating: Tin
  • Width: 34.04 mm
  • Height: 22.05 mm
  • Depth: 31.89 mm
  • Contacts: 20
  • Popularity: Low
  • RoHS Compliant: Yes
  • Halogen-Free: Yes
