22-27-2151 Real Image
Same model may have multiple batches, images only for reference.

22-27-2151

Part No 22-27-2151
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 15 Circuits, Tin (Sn) Plating
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color White
Contact Gender Male
Contact Material Brass
Contact Plating Tin
Contact Resistance 10 mΩ
Country of Origin US
Current Rating 4 A
Depth 3.6 mm
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Height 4.5 mm
Hole Diameter 1.02 mm
Housing Material Nylon
Lead Pitch 2.54 mm
Length 16.8 mm
Material Nylon
Maximum Operating Temperature 75 °C
Min Operating Temperature 0 °C
Mount Cable, Through Hole
Number of Circuits 15
Number of Contacts 15
Number of Pins 15
Number of Poles 15
Number of Positions 15
Number of Rows 1
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Voltage Rating (AC) 250 V
Voltage Rating (DC) 250 V
Working Voltage 250 V
Win Source Part Number 991805-22-27-2151
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 22-27-2151 CAD Model

Description

This Molex 991805-22-27-2151 connector is a high-quality electronic component that is perfect for use in various applications.

  • Positions: 15
  • Pitch: 2.54 mm
  • Material: Nylon
  • Contact Material: Brass
  • Voltage Rating: 250 V
  • Current Rating: 4 A
