The 08-56-0110 is a Molex connector, specifically a KK 254 series header. These headers are commonly used for making board-to-board or wire-to-board connections in a variety of electronic applications. The KK series is known for its reliability and versatility.

Applications

• Printed Circuit Boards (PCBs): Used for connecting various components on a PCB.
• Wire-to-Board Connections: Mating with crimp terminals attached to wires for connecting external devices.
• Signal Connections: Transmitting low-voltage signals between boards or devices.
• Power Connections: Delivering low-current power to various circuit sections.
• Control Systems: Connecting sensors, actuators, and other control elements.

Features

• Number of Circuits: 11. This specifies the number of individual connection points on the header.
• Pitch: 2.54mm (0.1 inch). This is the distance between the centers of adjacent pins. This pitch is a very common standard.
• Row: Single Row. Pins are arranged in a single line.
• Mating Style: Vertical. Mates vertically with a corresponding KK 254 series connector.
• Termination Style: Through-hole. Designed to be soldered directly onto a PCB.

Benefits

• Reliable Connection: Provides a secure and dependable connection for signals and power.
• Versatile: Suitable for a wide range of applications due to its standard pitch and various mating options.
• Easy to Use: Simple to install and mate with corresponding connectors.
• Cost-Effective: Offers a balance of performance and affordability.
• Industry Standard: KK 254 series is a widely recognized and supported connector family.

Additional Details

The 08-56-0110 header, part of the Molex KK 254 series, is a reliable and versatile connector suitable for various electronic applications. Its 2.54mm pitch makes it compatible with a wide range of standard components and PCBs. The vertical mating style simplifies board-to-board connections. The through-hole termination ensures a secure and robust connection to the PCB. Molex is a well-known and trusted manufacturer of connectors, ensuring the quality and reliability of this product. When selecting a mating connector, ensure it is a compatible KK 254 series connector designed for vertical mating. This connector is commonly used in consumer electronics, industrial equipment, and automotive applications.
