The 22035025 is a Milli-Grid connector manufactured by Molex, LLC. It is a versatile, high-density connector system designed for signal applications in a wide range of electronic equipment. Known for its compact size and reliable performance, Milli-Grid connectors are used where space is at a premium.

Applications

• Board-to-board connections
• Wire-to-board connections
• Signal transmission in embedded systems
• Data communication equipment
• Medical devices

Features

• Milli-Grid connector system
• High-density design (2.00mm pitch)
• Available in single and dual row configurations
• Surface mount and through-hole options
• Polarized housing
• Gold or tin plating options

Benefits

• Space savings due to its compact size, enabling miniaturization of electronic devices.
• Flexible design options with various row configurations and mounting styles to suit different board layouts.
• Reliable signal transmission ensured by gold or tin plating options, minimizing contact resistance.
• Prevention of mis-mating with the polarized housing, simplifying assembly and reducing errors.
• Versatile application due to support for both board-to-board and wire-to-board connections.

Additional Details

The Milli-Grid connector system is a popular choice for applications requiring high-density signal connections. The 22035025 part number designates a specific configuration within the Milli-Grid family, encompassing aspects such as row count, number of circuits, plating material, and mounting style. The 2.00mm pitch allows for a large number of signals to be routed in a small area. Molex offers a wide range of tooling and accessories to support the Milli-Grid connector system.

Technical Specifications (Typical):

• Pitch: 2.00 mm
• Current Rating: Refer to datasheet for specific current rating per contact
• Voltage Rating: Refer to datasheet for voltage rating
• Operating Temperature: Refer to datasheet for operating temperature range
• Contact Material: Typically phosphor bronze with gold or tin plating
