SMBJ5360B-TP Real Image SMBJ5360B-TP Real Image1 SMBJ5360B-TP Real Image2
Same model may have multiple batches, images only for reference.
SMBJ5360B-TP Real Image SMBJ5360B-TP Real Image1 SMBJ5360B-TP Real Image2
SMBJ5360B-TP Real Image SMBJ5360B-TP Real Image1 SMBJ5360B-TP Real Image2
Same model may have multiple batches, images only for reference.

SMBJ5360B-TP

Part No SMBJ5360B-TP
Manufacturer Micro Commercial Co
Catalog Diodes - Zener - Single
Description DIODE ZENER 25V 5W DO214AA
Datasheet
SMBJ5360B-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 25V
Tolerance ±5%
Maximum Power Dissipation 5W
Impedance (Max) (Zzt) 4 Ohm
Current - Reverse Leakage @ Vr 500nA @ 19V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 1A
Temperature Range - Operating -55°C to 150°C
Mounting SMD (SMT)
Case / Package DO-214AA (SMB)
Win Source Part Number 1097822-SMBJ5360B-TP
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian SMBJ5360B-TP CAD Model

Description

The SMBJ5360B-TP is a Zener diode manufactured by Micro Commercial Co.

  • Voltage - Forward (Vf) (Max) @ If: 1.2V @ 1A
  • Current - Reverse Leakage @ Vr: 500nA @ 19V
  • Voltage - Zener (Nom) (Vz): 25V
  • Tolerance: ±5%
  • Impedance (Max) (Zzt): 4 Ohm
  • Power - Max: 5W
  • Package / Case: DO-214AA (SMB)
  • Operating Temperature: -55°C ~ 150°C
