MBR0540-TP Real Image MBR0540-TP real image10597
Same model may have multiple batches, images only for reference.
MBR0540-TP Real Image MBR0540-TP real image10597
MBR0540-TP Real Image MBR0540-TP real image10597
Same model may have multiple batches, images only for reference.

MBR0540-TP

Part No MBR0540-TP
Manufacturer Micro Commercial Co
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 500MA SOD123
Datasheet
MBR0540-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 550mV @ 500mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 40V
Capacitance @ Vr, F 30pF @ 4V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-123
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 1072371-MBR0540-TP
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MBR0540-TP CAD Model

Description

The MBR0540-TP is a Schottky diode manufactured by Micro Commercial Co.

  • Maximum Reverse Voltage: 40V
  • Average Rectified Current: 500mA
  • Forward Voltage: 550mV @ 500mA
  • Reverse Leakage Current: 200μA @ 40V
  • Capacitance: 30pF @ 4V, 1MHz
  • Mounting: SMD (SMT)
  • Package: SOD-123
  • Operating Temperature: -55°C to 150°C
  • Quantity per Package: 3,000
