Same model may have multiple batches, images only for reference.

SMBJ190CA

Name: SMBJ190CA
Brand: MERITEK ELECTRONICS CORPORATION
SKU: 668785
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMBJ190CA
Manufacturer	MERITEK ELECTRONICS CORPORATION
Catalog	TVS - Diodes
Description	TVS DIODE 190VWM 307.8VC / 307.8V Clamp 1.95A Ipp Tvs Diode Surface Mount
Datasheet	SMBJ190CA Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	MERITEK ELECTRONICS CORPORATION
Series	SMBJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Bidirectional Channels	1
Voltage - Reverse Standoff (Typ)	190V
Voltage - Breakdown (Min)	211V
Voltage - Clamping (Max) @ Ipp	307.8V
Current - Peak Pulse (10/1000µs)	1.95A
Power - Peak Pulse	600W
Applications	General Purpose
Temperature Range - Operating	-55°C ~ 150°C
Mounting Type	Surface Mount
Package / Case	DO-214AA (SMB)
Standard Package	20 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	668785-SMBJ190CA
Ultra Librarian 3D Model	Ultra Librarian SMBJ190CA CAD Model

Alternative Products

Description

The SMBJ190CA is a Zener type TVS diode from Meritek Electronics Corporation.

Series: SMBJ
Reverse Standoff Voltage: 190V
Breakdown Voltage: 211V
Clamping Voltage @ a Peak Pulse Current of 1.95A: 307.8V
Power Rating: 600W
Mounting Type: Surface Mountable
Package: DO-214AA (SMB)
Operating Temperature Range: -55°C to 150°C
Manufacturer: Meritek Electronics Corporation
