The MLX90614ESF-DCC is a non-contact infrared (IR) thermometer designed and manufactured by Melexis Technologies NV. This versatile sensor allows for temperature measurement without physical contact, making it suitable for a wide range of applications. It integrates an IR thermopile detector and a signal conditioning ASIC in a single TO-39 package.

Applications

• Body temperature measurement: Used in forehead thermometers for non-contact body temperature monitoring.
• Industrial temperature control: Employed in industrial processes for monitoring and controlling temperature without physical contact.
• Automotive applications: Utilized in climate control systems to measure cabin and component temperatures.
• Appliance temperature monitoring: Integrated into appliances such as ovens and refrigerators for temperature monitoring.
• Movement detection: Can be used to detect movement based on temperature changes in the environment.

Features

• Non-contact temperature measurement: Measures temperature without physical contact.
• High accuracy: Offers high accuracy over a wide temperature range.
• SMBus compatible digital interface: Provides a digital interface for easy integration with microcontrollers.
• Small size: Compact TO-39 package for easy integration into various applications.
• Wide temperature range: Measures object temperatures from -70°C to +380°C.

Benefits

• Safe temperature measurement: Allows for safe measurement of hot or hazardous objects.
• Improved accuracy: Provides accurate temperature readings for reliable performance.
• Easy integration: Digital interface simplifies integration with existing systems.
• Versatile applications: Suitable for a wide range of applications requiring non-contact temperature measurement.
• Cost-effective: Offers a cost-effective solution for temperature monitoring.

Specifications

The MLX90614ESF-DCC operates on a supply voltage of 3V and has a typical current consumption of 3mA. It communicates via SMBus and provides a digital output of the measured temperature. The sensor's accuracy is typically ±0.5°C around room temperature. The field of view (FOV) is approximately 90 degrees. It is designed to be robust and reliable in a wide range of environmental conditions.

This sensor utilizes advanced infrared technology to accurately measure temperature without contact, making it an ideal choice for applications where safety and precision are critical. Its compact size and digital interface further enhance its versatility and ease of integration into various electronic systems.
