Product Overview: MAX6836WXSD1-T from Maxim Integrated

The MAX6836WXSD1-T is a highly reliable, low-power microprocessor (µP) supervisory circuit designed by Maxim Integrated to monitor power supplies in µP and digital systems. It provides a significant level of system protection by ensuring that the µP boots up in a known state and by monitoring the power supply to prevent code execution errors during low-voltage conditions.

Key Features

• Precision Monitoring: This device features a precision voltage monitor with a factory-set reset threshold voltage, ensuring accurate monitoring of the VCC supply.
• Low Power Consumption: The MAX6836WXSD1-T is tailored for battery-operated and portable applications, with a low quiescent current that extends battery life.
• Manual Reset Input: A manual reset input allows for a system reset to be triggered with an external push-button or logic signal, providing an additional layer of system control.
• Reset Timeout: The device offers a fixed reset timeout delay, which guarantees the system has sufficient time to stabilize before resuming operation after a reset event.
• Compact Package: Available in a small, 5-pin SC70 package, the MAX6836WXSD1-T is designed to save space on densely populated circuit boards.

Applications

With its robust feature set, the MAX6836WXSD1-T is an ideal choice for a variety of applications, including:

• Portable/Battery-Powered Equipment
• Embedded Systems
• Microprocessor-Based Devices
• Industrial Controllers
• Handheld Consumer Electronics

Quality and Reliability

Maxim Integrated is known for its commitment to quality, and the MAX6836WXSD1-T is no exception. It is manufactured to the highest standards to ensure consistent performance and reliability in critical applications. The device's operating temperature range and robust design make it suitable for use in both commercial and industrial environments.

In summary, the MAX6836WXSD1-T from Maxim Integrated is a versatile and reliable solution for µP system monitoring, offering precision voltage monitoring, low power consumption, manual reset functionality, and a compact form factor. It is a valuable component for designers looking to enhance system reliability and performance in a wide range of electronic products.
