Maxim Integrated DS1338U-33+T Real-Time Clock

The DS1338U-33+T is a highly integrated real-time clock (RTC) from Maxim Integrated that provides a comprehensive timekeeping solution for a wide range of applications. This RTC is designed to maintain accurate time and date information, from seconds to years, with minimal power consumption, making it ideal for battery-backed or portable devices.

Operating from a 2.0V to 5.5V supply voltage, the DS1338U-33+T is versatile and can be integrated into systems with varying power requirements. It features a built-in power-sense circuit that detects power failures and automatically switches to the backup supply, ensuring continuous timekeeping. This makes it a reliable choice for critical applications where maintaining an accurate time base is essential, even during power interruptions.

The device comes in a compact 8-pin µSOP package, making it suitable for space-constrained applications. The DS1338U-33+T offers a serial I²C interface for easy integration into existing designs, allowing for simple communication with microcontrollers and other digital systems.

One of the key features of the DS1338U-33+T is its trickle-charge capability, which enables the RTC to recharge a backup battery or supercapacitor during normal operation. This ensures that the timekeeping function remains powered for extended periods, even when the main power supply is unavailable.

Additionally, the DS1338U-33+T includes two programmable time-of-day alarms and a programmable square-wave output. These features provide designers with the flexibility to implement various time-related functions, such as wake-up alarms or periodic system checks, without the need for additional components.

In summary, the Maxim Integrated DS1338U-33+T real-time clock is a compact, power-efficient, and feature-rich component that offers a reliable timekeeping solution for applications such as embedded systems, portable devices, industrial controls, and telecommunications. Its ease of integration, coupled with its robust set of features, makes it an excellent choice for designers looking to add accurate time and date functionality to their products.
