SD24C-01FTG Real Image SD24C-01FTG real image11017
Same model may have multiple batches, images only for reference.
SD24C-01FTG Real Image SD24C-01FTG real image11017
SD24C-01FTG Real Image SD24C-01FTG real image11017
Same model may have multiple batches, images only for reference.

SD24C-01FTG

Part No SD24C-01FTG
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 24VWM 42VC SOD323
Datasheet
SD24C-01FTG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 24V (Max)
Max Clamping Voltage 42V
Peak Pulse Current(Ippm) 7A (8/20μs)
Power Dissipation - Pd 450W
Applications Automotive
Capacitance @ Frequency 50pF @ 1MHz
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-323
Win Source Part Number 1094982-SD24C-01FTG
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SD24C-01FTG CAD Model

Description

The SD24C-01FTG is a Zener type circuit protection component that is designed for automotive applications from Littelfuse Inc.

  • Type: Zener
  • Applications: Automotive
  • Channel: Bidirectional
  • Capacitance: 50pF @ 1MHz
  • Mounting: SMD (SMT)
  • Packaging: Reel - TR
  • STAND-OFF Voltage (Vwm): 24V (Max)
  • Maximum Clamping Voltage: 42V
  • Peak Pulse Current(Ippm): 7A (8/20μs)
  • Power Dissipation - Pd: 450W
  • Popularity: Medium
  • Supply and Demand Status: Sufficient
