The LTC2804IGN-1#TRPBF is a high-performance, dual RS232 transceiver IC from Linear Technology, now part of Analog Devices, designed to meet the requirements of modern serial communication protocols. This integrated circuit provides two RS232 transceiver channels that are capable of running at data rates up to 1Mbps, making it an ideal choice for fast and reliable data transfer applications.

Key Features

• Dual RS232 Transceivers: The device includes two independent RS232 transceiver channels, each capable of operating at high data rates.
• High-Speed Interface: With support for data rates up to 1Mbps, the LTC2804IGN-1#TRPBF can handle high-speed data communication with ease.
• Low Power Consumption: Designed with power efficiency in mind, it operates with a low supply current, making it suitable for battery-powered and portable applications.
• Robust ESD Protection: The transceivers feature ±15kV ESD protection on transmitter outputs and receiver inputs, providing robust protection against electrostatic discharge events.
• Wide Operating Temperature Range: It is specified for operation from -40°C to 85°C, ensuring reliable performance in a broad range of environments.
• Small Footprint: The IC comes in a compact 16-pin SSOP package, which is ideal for space-constrained applications.

Applications

The LTC2804IGN-1#TRPBF is versatile and can be used in a variety of applications. It is particularly well-suited for portable or battery-powered devices, industrial equipment, data acquisition systems, point-of-sale terminals, and any other system that requires a reliable RS232 communication interface.

Quality and Reliability

Linear Technology's commitment to high-quality and reliable products is evident in the LTC2804IGN-1#TRPBF. The device is available in tape and reel packaging, designated by the #TRPBF suffix, which facilitates automated pick-and-place manufacturing processes, ensuring a reliable supply for volume production.
