GAL20V8B-25LP Lattice Semiconductor Corporation GAL20V8B-25LP real image
Same model may have multiple batches, images only for reference.
GAL20V8B-25LP Lattice Semiconductor Corporation GAL20V8B-25LP real image
GAL20V8B-25LP Lattice Semiconductor Corporation GAL20V8B-25LP real image
Same model may have multiple batches, images only for reference.

GAL20V8B-25LP

Part No GAL20V8B-25LP
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description High Performance E2CMOS PLD Generic Array Logic | IC CPLD 8MC 25NS 24DIP
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Tube
Status Obsolete
Programmable Type EE PLD
Delay Time tpd(1) Max 25.0ns
Voltage Supply - Internal 4.75V ~ 5.25V
Number of Macrocells 8
Temperature Range - Operating 0°C ~ 75°C
Mounting Style Through Hole
Manufacturer Package 24-DIP
Supplier Device Package 24-PDIP
Family Part Number GAL20V8
Manufacturer Pack Quantity 300
MSL Level 3 (168 Hours)
Win Source Part Number 1176808-GAL20V8B-25LP
Manufacturer Homepage www.latticesemi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GAL20V8B-25LP CAD Model

Description

The Lattice Semiconductor Corporation GAL20V8B-25LP is an obsolete EE PLD programmable IC with 8 macrocells. Bold the product name (e.g., BAV99S,135 → GAL20V8B-25LP) and manufacturer (e.g., Nexperia USA Inc. → Lattice Semiconductor Corporation).

  • Macrocells: 8
  • Maximum Delay Time: 25.0ns
  • Operating Temperature Range: 0°C to 75°C
  • Package: 24-PDIP
  • Voltage Supply: 4.75V to 5.25V
  • Series: GAL20V8
