The Kemet T520T106M12RAE080 is a high-performance solid electrolytic capacitor belonging to Kemet's T520 series. These capacitors are known for their Polymer Hermetic Molded Chip construction, which provides exceptional stability and low ESR (Equivalent Series Resistance), making them ideal for demanding applications.

Applications

• DC-DC Converters
• Power Management Circuits
• High-Frequency Switching Power Supplies
• Filtering and Decoupling in Electronic Circuits
• Voltage Regulation Modules (VRM)

Features

• Capacitance: 10µF
• Voltage Rating: 12.5V
• ESR (Equivalent Series Resistance): 80 mΩ
• Tolerance: ±20%
• Operating Temperature Range: -55°C to +125°C
• Case Size: EIA 7343-20
• Termination: Standard Termination
• RoHS Compliant

Benefits

• Low ESR: Minimizes power loss and heat generation, increasing efficiency in power applications.
• High Ripple Current Capability: Delivers stable performance under high current conditions, prolonging the capacitor's lifespan.
• Stable Performance: The polymer cathode ensures excellent capacitance retention and stability across a wide temperature range.
• Long Lifespan: The robust design and materials contribute to a long operational life, reducing the frequency of replacements.
• Compact Size: Efficient use of board space due to the capacitor's molded chip design.

Additional Details

The T520 series capacitors utilize a conductive polymer cathode, which offers significant advantages over traditional MnO2 capacitors, particularly in ESR and voltage derating characteristics. The 10µF capacitance provides effective filtering and energy storage. The 12.5V voltage rating is suitable for various power systems. The low ESR of 80 mΩ ensures minimal power losses and heat generation, leading to reliable operation in demanding circuits. This capacitor is designed for surface mount technology (SMT) and conforms to industry-standard dimensions for easy integration into automated assembly processes.

The device's high operating temperature range of -55°C to +125°C allows it to be used in harsh environments. The Polymer Hermetic Molded Chip construction provides enhanced protection against moisture and other environmental factors, further improving its reliability. The T520T106M12RAE080 is ideal for applications requiring high performance, stability, and longevity in a compact form factor, especially in power-sensitive designs.
