SM2518-R56MHF

Name: SM2518-R56MHF
Brand: ITG Electronics, Inc.
SKU: 895436
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	SM2518-R56MHF
Manufacturer	ITG Electronics, Inc.
Catalog	Fixed Inductors
Description	FIXED IND 560NH 20A 3.6MOHM SMD
Datasheet	SM2518-R56MHF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	ITG Electronics, Inc.
Series	SM2518
Package	Tape & Reel
Product Status	Active
Type	Molded
Material - Core	Metal
Inductance	560 nH
Tolerance	±20%
Current Rating (Amps)	20 A
Current - Saturation (Isat)	23A
Shielding	Shielded
DC Resistance (DCR)	3.6mOhm Max
Temperature Range - Operating	-55°C ~ 150°C
Inductance Frequency - Test	100 kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.270" L x 0.255" W (6.86mm x 6.47mm)
Height - Seated (Max)	0.197" (5.00mm)
Standard Package	500 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	895436-SM2518-R56MHF
Ultra Librarian 3D Model	Ultra Librarian SM2518-R56MHF CAD Model

Alternative Products

Description

The SM2518-R56MHF is a molded fixed inductor from ITG Electronics Inc.

Series: SM2518
Size: 0.270" L x 0.255" W (6.86mm x 6.47mm)
Inductance: 560 nH
Tolerance: ±20%
Seated Height: 0.197" (5.00mm) Max
DC Resistance (DCR): 3.6mOhm Max
Mounting: Surface Mountable
Package/Case: Nonstandard
Operating Temperature: -55°C to 150°C
Current Rating: 20 A
Saturation Current: 23A
