IRGP4068DPBF Real Image IRGP4068DPBF Real Image
Same model may have multiple batches, images only for reference.
IRGP4068DPBF Real Image IRGP4068DPBF Real Image
IRGP4068DPBF Real Image IRGP4068DPBF Real Image
Same model may have multiple batches, images only for reference.

IRGP4068DPBF

Part No IRGP4068DPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 600V 96A 330W TO247AC / Trans IGBT Chip N-CH 600V 96A 330000mW 3-Pin(3+Tab) TO-247AC Tube
Datasheet
IRGP4068DPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Bulk
Status Active
IGBT Type Trench
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 96A
Pulsed Collector Current 144A
Collector-emitter saturation voltage(Max) 2.14V @ 15V, 48A
Maximum Power Dissipation 330W
Total Switching Energy(Ets) 1.28mJ (off)
Input Type Standard
Gate Charge 95nC
Turn-on and Turn-off delay time -/145ns
Testing Conditions 400V, 48A, 10 Ohm, 15V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 016698-IRGP4068DPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRGP4068D
Introduction Date August 16, 2006
ECCN EAR99
Country of Origin Mexico
Halogen Free Not Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRGP4068DPBF CAD Model

Description

The IRGP4068DPBF is an active electronic component manufactured by Infineon Technologies. It is a TO-247AC case/package with a maximum collector-emitter breakdown voltage of 600V and a maximum power dissipation of 330W.
