Same model may have multiple batches, images only for reference.
IDW30G120C5BFKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IDW30G120C5BFKSA1

Part No IDW30G120C5BFKSA1
Manufacturer Infineon Technologies
Catalog Diodes, Rectifiers - Arrays
Description DIODE GEN PURP 1200V 44A TO247-3 / Diode Array 1 Pair Common Cathode Silicon Carbide Schottky 1200 V 44A (DC) Through Hole TO-247-3
Datasheet
IDW30G120C5BFKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Mfr Infineon Technologies
Series CoolSiC™+
Package Tube
Diode Configuration 1 Pair Common Cathode
Diode Type Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) 1200 V
Current - Average Rectified (Io) (per Diode) 44A (DC)
Voltage - Forward (Vf) (Max) @ If 1.65 V @ 15 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 124 µA @ 1200 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package PG-TO247-3
Base Product Number IDW30G120
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names SP001123716
Standard Package 30
Win Source Part Number 1064739-IDW30G120C5BFKSA1
Ultra Librarian 3D Model Ultra Librarian IDW30G120C5BFKSA1 CAD Model

Description

The IDW30G120C5BFKSA1 is a silicon carbide Schottky diode from Infineon Technologies.

  • Series: CoolSiC™+
  • Package: tube
  • Standard Package: 30 units
  • Diode Configuration: 1 pair common cathode
  • Voltage Output: 1200V
  • Recovery Speed: fast, less than 500ns
  • Current Output: 44A (DC) per diode
  • Alternative Parts Cross-Reference: RURG5060, RHRG5060, FFH50US60S, STTH100W04CW, STTH100W06CW, APT30S20BCTGIDW30G120C5B, and SP001123716
  • MSL Level: 1 (Unlimited)
  • REACH Status: REACH Unaffected
  • HTSUS: 8541.10.0080
  • Also Known As: SP001123716
  • Base Product Number: IDW30G120
