BTS5020-2EKA Real Image BTS5020-2EKA real image2839 BTS5020-2EKA real image2840
Same model may have multiple batches, images only for reference.
BTS5020-2EKA Real Image BTS5020-2EKA real image2839 BTS5020-2EKA real image2840
BTS5020-2EKA Real Image BTS5020-2EKA real image2839 BTS5020-2EKA real image2840
Same model may have multiple batches, images only for reference.

BTS5020-2EKA

Part No BTS5020-2EKA
Manufacturer Infineon Technologies
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC PWR SW HI-SIDE 2CH DSO14-40
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family PMIC - Power Distribution Switches, Load Drivers
Manufacturer Infineon Technologies
Series PROFET
Packaging Reel(TR)
Switch Type General Purpose
Number of Outputs 2
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Voltage - Load 8 V ~ 18 V
Operating Supply Voltage Not Required
Current - Output (Max) 5A
Rds On (Typ) 40 mOhm
Input Type Non-Inverting
Features Auto Restart
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature Range -40°C ~ 150°C (TJ)
Package 14-SOIC (0.154", 3.90mm Width) Exposed Pad
Manufacturer Device Package PG-DSO-14-40-EP
Win Source Part Number 012220-BTS5020-2EKA
Family Name BTS5020-2
Introduction Date January 01, 2000
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BTS5020-2EKA CAD Model

Description

Overview of BTS5020-2EKA

The BTS5020-2EKA is an advanced dual channel smart high-side switch with integrated protection mechanisms, designed to cater to demanding power control applications. Its compact and efficient design offers high operational reliability and versatility.

Features and Benefits

  • Dual channel configuration offers improved power handling capabilities.
  • Thermal shutdown feature for enhanced system safety.
  • Low stand-by current minimizes energy consumption.
  • Integrated PWM control ensures precise power modulation.

Applications

  • Automotive relay replacement in control units.
  • Lighting systems control in vehicles and industrial settings.
  • Home and building automation for efficient energy management.

Additional Details

The BTS5020-2EKA offers optimized load switching capabilities, making it ideal for modern applications requiring reliability and efficiency.
