The PEEL18CV8ZT-25L is a low-power Programmable Electrically Erasable Logic (PEEL) device manufactured by ICT. This device is a versatile solution for implementing custom logic circuits, effectively replacing multiple standard logic gates. Its reprogrammable nature makes it ideal for applications that require frequent design modifications or updates without the need for hardware changes, leading to significant time and cost savings during development.

Applications

• Battery-powered devices: Due to its low power consumption, ideal for portable applications.
• Address decoding in memory systems: Used for selecting memory banks.
• State machine control: Employs programmable logic to manage sequential operations.
• Peripheral device interfacing: Facilitates communication between microcontrollers and peripherals.
• Combinatorial logic functions: Implementing logic functions in industrial control.

Features

• Low-power operation: Reduces power consumption compared to standard PEEL devices.
• High-speed performance: Offers a propagation delay of 25ns for fast processing.
• Electrically erasable and reprogrammable: Provides the ability to reprogram the device multiple times.
• Versatile I/O configuration: Allows for flexible allocation of input and output pins.
• TTL compatible: Ensures compatibility with standard TTL logic levels.

Benefits

• Extended battery life: Low-power consumption extends battery life in portable devices.
• Simplified design: Reduces component count by integrating multiple logic functions into a single device.
• Increased design flexibility: Enables quick changes and updates to the logic design without hardware modifications.
• Improved system reliability: Reduces the number of interconnections, improving system reliability.
• Cost-effective solution: Reduces development and manufacturing costs due to its reprogrammability.
