DF17(2.5)-26DP-0.5V(57) Real Image
Same model may have multiple batches, images only for reference.

DF17(2.5)-26DP-0.5V(57)

Part No DF17(2.5)-26DP-0.5V(57)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HDR 26POS SMD GOLD / 26 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Datasheet
DF17(2.5)-26DP-0.5V(57) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Hirose Electric Co Ltd
Series DF17
Package Tape & Reel
Connector Type Header, Outer Shroud Contacts
Number of Positions 26
Pitch 0.020" (0.50mm)
Number of Rows 2
Mounting SMD (SMT)
Features Board Guide, Solder Retention
Contact Finish Gold
Mated Stacking Heights 5.5mm, 6.5mm
Height Above Board 0.189" (4.80mm)
Base Product Number DF17
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names *DF17(2.5)-26DP-0.5V(57)-ND,*DF17(2.5)-26DP-0.5V(57)CT-ND,DF17(2.5)-26DP-0.5V(57)-ND,683-0245-4-57,H124577CT,H124577DKR,-DF17(2.5)-26DP-0.5V(57)-ND,-DF17(2.5)-26DP-0.5V(57)CT,-DF17(2.5)-26DP-0.5V(57),*DF17(2.5)-26DP-0.5V(57),H124577TR,-DF17(2.5)-26DP-0.5V(57)DKR,*DF17(2.5)-26DP-0.5V(57)DKR-ND
Standard Package 1,000
Win Source Part Number 974998-DF17(2.5)-26DP-0.5V(57)
Ultra Librarian 3D Model Ultra Librarian DF17(2.5)-26DP-0.5V(57) CAD Model

Description

The Hirose Electric Co Ltd DF17(2.5)-26DP-0.5V(57) is a rectangular connector that is designed for use in board to board applications.

  • Pitch: 0.020" (0.50mm)
  • Height Above Board: 0.189" (4.80mm)
  • Positions: 26
  • Mounting Technology: SMD (SMT)
  • Standard Package: 1,000
  • Features: Board Guide and Solder Retention
  • Ideal for: Various electronic devices such as communication equipment, computers, and consumer electronics
