G125-FS11605L0P Real Image
Same model may have multiple batches, images only for reference.

G125-FS11605L0P

Part No G125-FS11605L0P
Manufacturer Harwin Inc.
Catalog Circular Connectors - Housings
Description CONN RCPT 16POS 0.049 GOLD SMD / 16 Position Receptacle Connector 0.049" (1.25mm) Surface Mount Gold
Datasheet
G125-FS11605L0P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Harwin Inc.
Series Gecko
Package Strip
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board or Cable
Number of Positions 16
Number of Positions Loaded All
Pitch - Mating 0.049" (1.25mm)
Number of Rows 2
Row Spacing - Mating 0.049" (1.25mm)
Mounting SMD (SMT)
Termination Solder
Fastening Type Latch Holder
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 8.00µin (0.203µm)
Insulation Color Green
Insulation Height 0.207" (5.25mm)
Temperature Range - Operating -65°C ~ 150°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Gold
Features Pick and Place, Polarizing Key
Current Rating (Amps) 2A
Applications Automotive, General Purpose
Insulation Material Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Contact Shape Circular
Contact Material Copper Alloy
Base Product Number G125-FS1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names G125-FS11605L0P-ND,952-2435
Standard Package 10
Win Source Part Number 1142819-G125-FS11605L0P
Ultra Librarian 3D Model Ultra Librarian G125-FS11605L0P CAD Model

Description

The Gecko G125-FS11605L0P is a part of the Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets category.

  • Positions: 16
  • Features: Pick and place, polarizing key
  • Connector Type: Receptacle
  • Contact Type: Female Socket
  • Package Type: Strip
  • Mounting Style: SMD (SMT)
  • Pitch-Mating: 0.049" (1.25mm)
  • Applications: Automotive and general-purpose
  • MSL Level: Unlimited
  • Current Rating: 2A
