09670150425 HARTING – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

09670150425

Part No 09670150425
Manufacturer HARTING
Catalog D - Sub, D - Shaped Connectors - Backshells, Hoods
Description CONN BACKSHELL 15POS 180DEG SHLD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Accessory Type Hinged Backshell
Number of Positions 15
Compatible Shell Size A
Compatible D-Sub Size 15pos and HD26pos
Cable Type Round
Cable Exit 180°
Shielding Shielded
Primary Material Plastic
Material Thermoplastic, Metallized
Hardware Cable Clamp, Grommets
Features Locking, Mating Screws 4-40
Package Bag
Supply and Demand Status Shortage
Win Source Part Number 1621683-09670150425
Ultra Librarian 3D Model Ultra Librarian 09670150425 CAD Model
