Part No 148M
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description AUDIO XFMR 6K / 2K 500/500 TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Impedance - Primary (Ohms) 6k
Impedance - Secondary (Ohms) 2k, 500/500
DC Resistance (DCR) - Primary 850Ohm
DC Resistance (DCR) - Secondary 230Ohm
Transformer Type Economical Open Type
Frequency Range 200Hz ~ 15kHz
Frequency Response ±1dB
Insertion Loss 0.5dB
Power Level 75mW
Mounting Type Through Hole
Size / Dimension 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) 0.690" (17.53mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1511075-148M
Ultra Librarian 3D Model Ultra Librarian 148M CAD Model
