MPXV5010GC6T1 Freescale Semiconductor - NXP MPXV5010GC6T1 Real Image MPXV5010GC6T1 label picture
Same model may have multiple batches, images only for reference.
MPXV5010GC6T1 Freescale Semiconductor - NXP MPXV5010GC6T1 Real Image MPXV5010GC6T1 label picture
MPXV5010GC6T1 Freescale Semiconductor - NXP MPXV5010GC6T1 Real Image MPXV5010GC6T1 label picture
Same model may have multiple batches, images only for reference.

MPXV5010GC6T1

Part No MPXV5010GC6T1
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR PRESSURE GAUGE SMD 8SOP
Datasheet
MPXV5010GC6T1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Vented Gauge
Operating Pressure 1.45 PSI (10 kPa)
Output Type Analog Voltage
Output 0.2 V to 4.7 V
Accuracy ±5%
Supply Voltage - Operating 4.75 V to 5.25 V
Port Size Male - 0.13" (3.17mm) Tube
Port Style Barbless
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 5.8 PSI (40 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 024335-MPXV5010GC6T1
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MPXV5010GC6T1 CAD Model

Description

The NXP MPXV5010GC6T1 is a temperature compensated, vented gauge pressure sensor with an output type of analog voltage ranging from 0.2V to 4.7V and an accuracy of ±5%.

  • Port Size: Male 0.13" (3.17mm) tube
  • Port Style: Barbless
  • Operating Pressure: 1.45 PSI (10 kPa)
  • Maximum Pressure: 5.8 PSI (40 kPa)
  • Temperature Range: -40°C to 125°C
  • Supply Voltage: 4.75V to 5.25V
  • Category: Sensors and transducers
  • Status: Active
  • Supply and Demand: Limited
