MC13202FCR2 Real Image MC13202FCR2 real image2711 MC13202FCR2 Real Image1 MC13202FCR2 Real Image2
Same model may have multiple batches, images only for reference.
MC13202FCR2 Real Image MC13202FCR2 real image2711 MC13202FCR2 Real Image1 MC13202FCR2 Real Image2
MC13202FCR2 Real Image MC13202FCR2 real image2711 MC13202FCR2 Real Image1 MC13202FCR2 Real Image2
Same model may have multiple batches, images only for reference.

MC13202FCR2

Part No MC13202FCR2
Manufacturer Freescale Semiconductor - NXP
Catalog RF Transceiver ICs
Description IC RF TXRX 802.15.4/ISM 32-VFQFN
Datasheet
MC13202FCR2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer NXP
Packaging Reel - TR
Status Not For New Designs
Type TxRx Only
RF Family/Standard 802.15.4, General ISM > 1GHz
Protocol Zigbee
Modulation DSSS, O-QPSK
Frequency 2.4GHz
Data Rate (Max) 250kbps
Power - Output 4dBm
Sensitivity -92dBm
Serial Interfaces SPI
GPIO 7
Supply Voltage - Operating 2 V to 3.4 V
Current - Receiving 37mA
Current - Transmitting 30mA
Temperature Range - Operating -40°C to 85°C
Dimension 32-VFQFN Exposed Pad
Win Source Part Number 022544-MC13202FCR2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MC13202FCR2 CAD Model

Description

The NXP 022544-MC13202FCR2 is a Zigbee TxRx Only module that operates at a frequency of 2.4GHz.

  • Power Output: 4dBm
  • Sensitivity: -92dBm
  • Data Rate: 250kbps
  • Current Consumption (Receiving): 37mA
  • Current Consumption (Transmitting): 30mA
  • Modulation Techniques: DSSS and O-QPSK
  • GPIO Pins: 7
  • Serial Interface: SPI
  • Temperature Range: -40°C to 85°C
  • Operating Voltage: 2V to 3.4V
