NC7SZ14P5X

Name: NC7SZ14P5X
Brand: Fairchild/ON Semiconductor
SKU: 250095
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NC7SZ14P5X
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	Inverter Schmitt Trigger 1-Element CMOS 5-Pin SC-70 T/R / IC INVERTER UHS SCHMITT SC70-5
Datasheet	NC7SZ14P5X Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	1
Number of Inputs	1
Features	Schmitt Trigger
Supply Voltage - Operating	1.65 V to 5.5 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	32mA, 32mA
Logic Level - Low	0.2 V to 1.2 V
Logic Level - High	1.4 V to 3.6 V
Max Propagation Delay @ V, Max CL	5.9ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	SC-70-5
Dimension	5-TSSOP, SC-70-5, SOT-353
Win Source Part Number	024819-NC7SZ14P5X
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Quantity per package	3k pcs
Family Name	NC7SZ14
Introduction Date	January 16, 2001
ECCN	EAR99
Country of Origin	China, Malaysia , Philippines, Thailand
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian NC7SZ14P5X CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor NC7SZ14P5X is a Schmitt trigger inverter with one circuit and one input.

Type: Schmitt trigger inverter
Circuits: 1
Inputs: 1
Maximum Propagation Delay: 5.9ns @ 5V and 50pF
Logic Level Low: 0.2V to 1.2V
Logic Level High: 1.4V to 3.6V
Temperature Range: -40°C to 85°C
Package: SC-70-5
Supply Voltage: 1.65V to 5.5V
