MOC3052M Real Image MOC3052M real image3538
Same model may have multiple batches, images only for reference.
MOC3052M Real Image MOC3052M real image3538
MOC3052M Real Image MOC3052M real image3538
Same model may have multiple batches, images only for reference.

MOC3052M

Part No MOC3052M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Triac, SCR Output
Description OPTOISOLATOR 4.17KV TRIAC 6DIP
Datasheet
MOC3052M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Triac
Zero Crossing Circuit No
Number of Channels 1
Isolation Voltage 4170Vrms
Voltage - Off State 600V
Static dV/dt (Min) 1kV/μs
Current - LED Trigger (Ift) (Max) 10mA
Current - Hold (Ih) 220μA (Typ)
Forward Voltage 1.18V
Continuous forward current- Max 60mA
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 6-DIP
Approvals UR
Win Source Part Number 024187-MOC3052M
Family Name MOC3052M
Introduction Date April 14, 2003
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Consumer Electronics, Motor Drive & Control, Industrial, Power Management, Lighting
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian MOC3052M CAD Model

Description

The supply and demand status of the product is sufficient.

  • Approval: UR
  • Mounting: Through Hole
  • Output Type: Triac
  • Forward Voltage: 1.18V
  • Voltage-Off State: 600V
  • Channel: 1
  • Isolation Voltage: 4170Vrms
  • Current Hold: 220μA (Typ)
  • Family: MOC3052M
  • Zero Crossing Circuit: Yes
  • Static dV/dt (Min): 1kV/μs
  • Current-LED Trigger (Ift) (Max): 10mA
  • Turn On Time: Not Available
  • Applications: Consumer Electronics, Motor Drive and Control, Industrial, Power Management, and Lighting
  • Halogen-Free: Yes
  • Package: 1k pcs per package
