LM336Z5

Part No LM336Z5
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Reference
Description Programmable Shunt Regulator
Datasheet
LM336Z5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Fairchild/ON Semiconductor
Packaging Bulk
Reference Type Shunt
Output Type Fixed
Output Voltage 5V
Output Current 15mA
Tolerance ±4%
Current - Cathode 10mA
Operating Temperature Range 0°C ~ 70°C (TA)
Mounting Style Through Hole
Package TO-226-3, TO-92-3 (TO-226AA)
Manufacturer Package TO-92-3
Win Source Part Number 1198704-LM336Z5
Manufacturer Homepage www.fairchildsemi.com
Family Name LM336
Introduction Date November 12, 2002
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Popularity Medium
Supply and Demand Status Balance
Quantity per package 10k pcs
Ultra Librarian 3D Model Ultra Librarian LM336Z5 CAD Model

Description

The Fairchild/ON Semiconductor LM336Z5 is a shunt voltage reference that outputs a fixed 5V.

  • Output Voltage: 5V
  • Package: TO-92-3
  • Tolerance: ±4%
  • Category: ICs
  • ECCN: EAR99
  • Supply and Demand Status: Balanced
  • Manufacturer Pack Quantity: 10,000
  • Operating Temperature Range: 0°C to 70°C
  • HTSUS: 8542.21.0000
