H11B1SM Real Image
Same model may have multiple batches, images only for reference.

H11B1SM

Part No H11B1SM
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 4.17KV DARL W/BASE 6SMD / DC-IN 1-CH Darlington With Base DC-OUT 6-Pin PDIP SMD Bag
Datasheet
H11B1SM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube
Number of Channels 1
Voltage - Isolation 4170Vrms
Current Transfer Ratio (Minimum) 500% @ 1mA
Turn On / Turn Off Time (Typ) 25μs, 18μs
Input Type DC
Output Type Darlington with Base
Output Voltage MAX 30V
Output Current per Channel 150mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Maximum) 80mA
Vce Saturation (Maximum) 1V
Operating Temperature Range -40°C ~ 100°C
Mounting SMD
Package 6-SMD, Gull Wing
Manufacturer Package 6-SMD
Win Source Part Number 775526-H11B1SM
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1,300
Family Name H11B1M
Introduction Date May 17, 2007
ECCN EAR99
Country of Origin Thailand
Halogen Free Not Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian H11B1SM CAD Model

Description

The Fairchild/ON Semiconductor H11B1SM is a Darlington with Base output type electronic component from Fairchild/ON Semiconductor.

  • Input Type: DC
  • Family Name: H11B1M
  • Voltage Isolation: 4170Vrms
  • Output Voltage (Max): 30V
  • Win Source Part Number: 775526-H11B1SM
  • Estimated EOL Date: 2028
