Part No SE2301
Manufacturer Epson Electronics America Inc-Semiconductor Div
Catalog Oscillators
Description OSC XO 28.322MHZ CMOS TTL SMD
Datasheet
SE2301 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Crystals, Oscillators, Resonators
Manufacturer EPSON
Packaging Cut Reel
Status Obsolete(EOL)
Type XO (Standard)
Frequency 28.322MHz
Purpose Enable/Disable
Output CMOS, TTL
Supply Voltage - Operating 5V
Frequency Stability ±100ppm
Temperature Range - Operating -20°C to 70°C
Current - Supply (Max) 35mA
Mounting SMD (SMT)
Dimension 0.551" L x 0.341" W (14.00mm x 8.65mm)
Height - Seated (Max) 0.185" (4.70mm)
Current - Supply (Disable) (Max) 12mA
Win Source Part Number 046820-SE2301
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SE2301 CAD Model

Description

The EPSON SE2301 is a surface mount XO (standard) with a frequency of 28.322MHz and a frequency stability of ±100ppm.

  • Frequency: 28.322MHz
  • Frequency Stability: ±100ppm
  • Current Supply: 35mA (disable: 12mA)
  • Supply Voltage: 5V
  • Status: obsolete (EOL)
  • Popularity: medium popularity
  • Supply and Demand Status: balanced
  • Packaging: cut reel packaging
  • Dimension: 0.551" L x 0.341" W (14.00mm x 8.65mm)
