KBPC804 Real Image
Same model may have multiple batches, images only for reference.

KBPC804

Part No KBPC804
Manufacturer DIOTEC Electronics Corporation
Catalog Bridge Rectifiers
Description 1PH BRIDGE 19X19X6.8 400V 8A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr DIOTEC Electronics Corporation
Package Box
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 400 V
Current - Average Rectified (Io) 5 A
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 4 A
Current - Reverse Leakage @ Vr 5 µA @ 400 V
Temperature Range - Operating -50°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-Square, KBPC-8
Supplier Device Package KBPC8
Standard Package 200 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
HTSUS 8541.10.0000
Win Source Part Number 610033-KBPC804
Ultra Librarian 3D Model Ultra Librarian KBPC804 CAD Model

Description

The 610033-KBPC804 is a single phase bridge rectifier diode suitable for various applications.

  • Package: Box
  • Standard Package Quantity: 200 pcs
  • Voltage Forward: 1.2V @ 4A
  • Voltage Peak Reverse: 400V
  • Average Rectified Current: 5A
  • Reverse Leakage Current: 5µA @ 400V
  • Operating Temperature: -50°C to 150°C
  • Manufacturer: DIOTEC Electronics Corporation
  • Product Line: Active
