Diodes Incorporated SMAJ90A-13-F TVS Diode

The SMAJ90A-13-F is a high-quality Transient Voltage Suppressor (TVS) diode from Diodes Incorporated, designed to provide robust overvoltage protection for sensitive electronics. This device is a part of the SMAJ series, which is well-regarded for its compact form factor and its ability to safeguard circuits against voltage spikes and surges that can occur due to lightning, electrostatic discharge (ESD), and other transient events.

Key Features

• Stand-Off Voltage: The SMAJ90A-13-F has a stand-off voltage of 90V, making it suitable for a wide range of applications that require this level of voltage protection.
• Peak Pulse Power: With a peak pulse power dissipation of 400W for 10/1000μs waveforms, this diode can handle significant power surges, providing reliable protection for your electronic components.
• Clamping Voltage: It features a low clamping voltage, which ensures that the voltage spike is limited to a safe level for the circuit components downstream.
• Uni-directional Protection: The SMAJ90A-13-F offers uni-directional surge protection, which is ideal for DC voltage applications where the polarity is fixed.
• DO-214AC Package: Encased in a DO-214AC (SMA) package, it not only offers a compact solution but also ensures ease of PCB layout and space-saving benefits.
• Compliance: This product is compliant with the RoHS and REACH standards, ensuring that it meets current environmental and safety regulations.

Applications

The SMAJ90A-13-F is versatile and can be used in a variety of applications, including:

• Power supply circuits
• Communication systems
• Automotive electronics
• Consumer electronics
• Industrial control systems

Its reliable performance and robust design make it an excellent choice for protecting sensitive electronic equipment from voltage transients. By integrating the SMAJ90A-13-F into your designs, you can enhance the durability and longevity of your electronic products, ensuring that they continue to function optimally even in the face of unpredictable voltage disturbances.

Whether you are designing for commercial or industrial applications, the SMAJ90A-13-F from Diodes Incorporated is an essential component for safeguarding your electronic circuits.
