The PI3USB302-AZBEX is a cutting-edge USB 3.0 differential switch from Diodes Incorporated, designed to facilitate the high-speed switching required for USB 3.0 signal routing. This versatile component offers an optimal solution for applications that need to switch between USB 3.0/3.1 Gen 1 data paths with minimal signal degradation.

Key Features

• High Bandwidth: With a bandwidth of 7.5 GHz, the PI3USB302-AZBEX ensures that the integrity of the high-speed USB 3.0 signals is maintained, providing reliable performance for critical applications.
• Low Crosstalk: The switch exhibits exceptionally low crosstalk at -30dB at 2.5 GHz, which is crucial for maintaining signal clarity and reducing interference between channels.
• Low On-Capacitance: Featuring a low on-capacitance (CON) of 4.5 pF (typical), the device minimizes capacitive loading on data lines, thereby enhancing signal integrity.
• Low On-Resistance: The low on-resistance (RON) of 6Ω (typical) offers reduced signal attenuation, ensuring that the USB 3.0 signals are transmitted with minimal loss.
• Power Efficiency: The PI3USB302-AZBEX is designed for power efficiency with an operational range of 3.0V to 3.6V, making it suitable for battery-powered devices.

Applications

The PI3USB302-AZBEX is ideal for a variety of applications, including but not limited to:

• Notebook and Desktop Computers
• Tablets and Smartphones
• Docking Stations
• USB Hubs and Peripherals
• High-Speed Data Acquisition Systems

Product Benefits

Integrating the PI3USB302-AZBEX into your design ensures seamless switching of USB 3.0 signals with high signal integrity. Its low-power consumption and small package size make it a highly attractive option for portable devices. The switch's high-performance characteristics ensure that it can support the fast data rates required by USB 3.0, making it an indispensable component for modern, high-speed data applications.

Conclusion

With its robust feature set and performance specifications, the PI3USB302-AZBEX from Diodes Incorporated stands out as a superior choice for designers looking to enhance the USB 3.0 data switching capabilities of their products. Its integration into your system promises to deliver speed, efficiency, and reliability, ensuring an optimal user experience.
