The BAT760-7 from Diodes Incorporated is a high-performance Schottky barrier diode designed for applications requiring fast switching and low power loss. This diode is housed in a compact SOD-123 package, making it ideal for space-constrained applications while offering robust thermal performance and reliability.

Key Features

• Low Forward Voltage Drop: The BAT760-7 offers a low forward voltage drop, which enhances power efficiency by minimizing power loss during operation.
• High Current Capability: This diode is capable of handling continuous forward currents, making it suitable for high-load applications.
• Fast Switching Speed: With its fast switching characteristics, the BAT760-7 is ideal for high-frequency applications, contributing to efficient circuit operation.
• Low Leakage Current: The device exhibits low leakage current, ensuring minimal power waste when the diode is in the reverse-biased state.

Applications

The BAT760-7 Schottky barrier diode is versatile and can be used in a range of applications, including:

• Power supply circuits
• DC-DC converters
• Reverse polarity protection
• Low voltage rectification
• High-frequency inverters
• Free-wheeling diodes in converters and motor control circuits

Product Specifications

The BAT760-7 boasts a range of specifications that make it an excellent choice for a variety of circuits:

Parameter Value Package SOD-123 Maximum Repetitive Reverse Voltage (V<sub>RRM) 60V Average Rectified Forward Current (I<sub>F(AV)) 1A Forward Voltage Drop (V<sub>F) 0.5V @ 1A Operating Junction Temperature (T<sub>j) -55°C to +125°C

Whether you're designing power management systems or looking for a reliable component for your switching applications, the BAT760-7 from Diodes Incorporated is engineered to deliver high efficiency and performance.
