The BAT750TA from Diodes Incorporated is a robust and efficient Schottky barrier rectifier designed for high-frequency miniature power supply applications. This rectifier is engineered to offer low forward voltage drop and high current capability, making it an ideal choice for use in a variety of electronic devices that require efficient power conversion and management.

Key Features

• Low Forward Voltage Drop: The BAT750TA features a low forward voltage drop, which enhances power efficiency and reduces thermal stress on the component during operation.
• High Current Capability: With its high current rating, this rectifier can handle significant current loads, making it suitable for demanding applications.
• Power Dissipation: It is designed to dissipate power effectively, ensuring reliable performance even under high load conditions.
• Guard Ring Die Construction: The guard ring die construction offers transient protection and ensures a long operational lifespan of the device.
• Lead-Free Finish: The BAT750TA is RoHS compliant and features a lead-free finish, making it an environmentally friendly choice for electronic manufacturers.

Applications

The BAT750TA is versatile and can be used in a wide range of applications, including:

• DC/DC converters
• Low voltage, high-frequency inverters
• Free-wheeling diodes
• Switching power supplies
• Power management devices

Specifications

Some of the key specifications of the BAT750TA include:

• Package: SOD-123 Flat Lead
• Maximum repetitive peak reverse voltage: 40V
• Maximum RMS voltage: 28V
• Maximum DC blocking voltage: 40V
• Maximum average forward rectified current: 0.75A
• Operating junction temperature range: -55°C to +150°C

In summary, the BAT750TA from Diodes Incorporated is a high-performance Schottky barrier rectifier that offers a blend of efficiency, reliability, and environmental compliance, making it an excellent choice for modern electronic applications.
