The AH5795-WU-7 is a high-performance, versatile Hall Effect sensor designed by Diodes Incorporated, a leading manufacturer in the semiconductor market. This sensor is engineered to meet the demanding requirements of modern electronic applications, providing reliable and accurate magnetic field detection.

Key Features

• Omni-polar Detection: Capable of detecting both north and south poles, this sensor offers flexibility in application design and simplifies installation.
• High Sensitivity: With its finely tuned detection capabilities, the AH5795-WU-7 can sense magnetic fields from a wide range of magnet strengths, making it suitable for a variety of uses.
• Low Power Consumption: Designed for efficiency, this sensor is an ideal choice for battery-powered devices, contributing to longer battery life and reduced energy costs.
• Chopper Stabilized Design: This feature ensures temperature stability and minimizes the influence of thermal and mechanical stress on the sensor's performance.

Applications

The AH5795-WU-7 Hall Effect sensor is highly versatile and can be utilized in a broad range of applications, including:

• Position and proximity sensing
• Brushless DC motor commutation
• Flow meters
• Speed detection
• Tachometers
• Linear and rotary encoders

Technical Specifications

The AH5795-WU-7 operates within a supply voltage range of 2.5V to 5.5V, making it compatible with most low-voltage systems. It is offered in an ultra-small W-DFN2020-6 (Type E) package, which allows for compact design footprints. Furthermore, its operating temperature range from -40°C to 85°C ensures reliable performance in diverse environmental conditions.

Quality and Reliability

Diodes Incorporated is committed to high standards of quality and reliability. The AH5795-WU-7 Hall Effect sensor is no exception, undergoing rigorous testing and quality assurance processes to ensure it meets the industry's highest standards for performance and durability.
