Diodes Incorporated 74LVC1G17SE-7 Product Overview

The 74LVC1G17SE-7 is a high-performance, single Schmitt-trigger buffer produced by Diodes Incorporated, designed to provide a robust interface between two logic families or to drive a heavily capacitive load. This integrated circuit (IC) is part of the LVC family, which is well-known for its low-voltage operation and compatibility with mixed voltage systems.

Key Features

• Advanced Technology: Manufactured with advanced CMOS technology, the 74LVC1G17SE-7 offers a power-efficient solution for modern electronic applications.
• Low Voltage Operation: The device operates at a supply voltage range of 1.65V to 5.5V, making it suitable for battery-operated and low-power systems.
• High Drive Capability: With the ability to drive up to 50mA at the output, this buffer can easily drive capacitive loads, offering design flexibility.
• 5V Tolerant Inputs: Inputs can tolerate up to 5V, even when the device is operated at a lower supply voltage, ensuring compatibility with higher voltage logic levels.
• Schmitt-Trigger Action: The Schmitt-trigger inputs provide hysteresis, which enhances noise immunity and allows for slow input transition, contributing to stable operation.
• ESD Protection: The IC features robust Electrostatic Discharge (ESD) protection, ensuring reliability and longevity in harsh environments.

Applications

The versatile nature of the 74LVC1G17SE-7 makes it suitable for a wide range of applications, including:

• Line drivers for signal buffering
• Logic level translation for mixed voltage systems
• Wave shaping and noise filtering for digital signals
• Driving heavy loads such as LEDs or relays
• Interface circuits in telecommunications and networking

Package and Quality

The 74LVC1G17SE-7 is available in an SOT-353 package, which is compact and suitable for space-constrained applications. Diodes Incorporated is committed to high-quality standards, and this product is rigorously tested to ensure performance and reliability.

Whether you are designing consumer electronics, industrial control systems, or portable devices, the 74LVC1G17SE-7 from Diodes Incorporated is a reliable and efficient choice for your buffering and interfacing needs.
