Same model may have multiple batches, images only for reference.

PYBJ6-D24-S5-D

Name: PYBJ6-D24-S5-D
Brand: CUI Inc.
SKU: 1339101
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	PYBJ6-D24-S5-D
Manufacturer	CUI Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 6W / Isolated Module DC DC Converter 1 Output 5V 1.2A 18V - 36V Input
Datasheet	PYBJ6-D24-S5-D Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	CUI Inc.
Series	PYBJ6 (6W)
Package	Tray
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	5V
Current - Output (Max)	1.2A
Power (Watts)	6 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OVP, SCP
Temperature Range - Operating	-40°C ~ 85°C
Efficiency	83%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Size / Dimension	1.28" L x 0.75" W x 0.27" H (32.6mm x 19.1mm x 6.8mm)
Approval Agency	CB Scheme, IEC, UL
Standard Number	62368-1
Base Product Number	PYBJ6
Standard Package	25
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1339101-PYBJ6-D24-S5-D
Ultra Librarian 3D Model	Ultra Librarian PYBJ6-D24-S5-D CAD Model

Alternative Products

Description

The PYBJ6 (6W) series is an isolated module type DC-DC converter manufactured by CUI Inc.

Series: PYBJ6 (6W)
Part Number: 1339101-PYBJ6-D24-S5-D
Mounting Type: through-hole
Power: 6W
Output Current: 1.2A
Input Voltage: 18V to 36V
Output Voltage: 5V
Features: remote on/off, OCP, OVP, and SCP
Category: Power Supplies - Board Mount - DC DC Converters
Application: ITE (Commercial)
Standard Package: 25
Packaging: tray
Market Availability: open market
