Part No 219-4LPSTRF
Manufacturer CTS Electrocomponents
Catalog DIP Switches
Description SWITCH SLIDE DIP SPST 100MA 20V / Dip Switch SPST 4 Position Surface Mount Slide (Standard) Actuator 100mA 20VDC
Datasheet
219-4LPSTRF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - DIP Switches
Mfr CTS Electrocomponents
Series 219
Package Tape & Reel
Product Status Active
Circuit SPST
Number of Positions 4
Current Rating (Amps) 100mA
Voltage Rating 20VDC
Actuator Type Slide (Standard)
Actuator Level Flush, Recessed
Contact Material Beryllium Copper
Contact Finish Gold
Height Above Board 0.160" (4.06mm)
Mounting Type Surface Mount
Termination Style Gull Wing
Pitch 0.100" (2.54mm), Full
Washable Yes
Features Epoxy Sealed Terminals, Tape Seal
Temperature Range - Operating -55°C ~ 85°C
Length 0.458" (11.63mm)
Electrical Life 2,000 Cycles
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
California Prop 65 Warning Information
Win Source Part Number 849461-219-4LPSTRF
Ultra Librarian 3D Model Ultra Librarian 219-4LPSTRF CAD Model

Description

The 219 series DIP switch by CTS Electrocomponents is a versatile electronic component that offers excellent performance and reliability.

  • Positions: 4
  • Pitch: 0.100" (2.54mm)
  • Termination Style: Gull-Wing
  • Contact Finish: Gold
  • Package: Tape and Reel
  • Voltage Rating: 20VDC
  • Current Rating: 100mA
  • Temperature Range: -55°C to 85°C
  • Features: Washable
