Same model may have multiple batches, images only for reference.

MGFW154812

Name: MGFW154812
Brand: Cosel USA, Inc.
SKU: 1060767
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	MGFW154812
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-12V / Isolated Module DC DC Converter 2 Output 12V or 24V -12V 650mA, 650mA 18V - 76V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	MGFW (15W)
Package	Box
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	18V
Voltage - Input (Max)	76V
Voltage - Output 1	12V or 24V
Voltage - Output 2	-12V
Current - Output (Max)	650mA, 650mA
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Bridgeable, Remote On/Off, OCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	87%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	1776-1357
Standard Package	1
Win Source Part Number	1060767-MGFW154812
Ultra Librarian 3D Model	Ultra Librarian MGFW154812 CAD Model

Alternative Products

Description

The Cosel USA MGFW154812 is a power supply module that belongs to the MGFW (15W) series.

Series: MGFW (15W)
Win Source Part Number: 1060767-MGFW154812
Application: ITE (Commercial)
Outputs: Two outputs
Maximum Output Current: 650mA each
Input Voltage Range: 18V to 76V
Efficiency: 87%
Features: Bridgeable, remote on/off and OCP
Benefits: Reliable and cost-effective solution for power supply circuits
Package: 6-DIP package
Operating Temperature Range: -40°C to 85°C
