Same model may have multiple batches, images only for reference.
MGFS102415 Cosel USA, Inc.
Same model may have multiple batches, images only for reference.

MGFS102415

Part No MGFS102415
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 15V 11W / Isolated Module DC DC Converter 1 Output 15V 700mA 9V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Cosel USA, Inc.
Series MGFS (10W)
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 15V
Voltage - Output 2 -
Voltage - Output 3 -
Voltage - Output 4 -
Current - Output (Max) 700mA
Power (Watts) 11 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 89%
Mounting Type Through Hole
Package / Case 7-SIP Module
Size / Dimension 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1355405-MGFS102415
Ultra Librarian 3D Model Ultra Librarian MGFS102415 CAD Model

Description

The Cosel USA MGFS102415 is a 10W isolated module DC-DC converter.

  • Features: Remote On/Off, OCP
  • Size / Dimension: 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
  • Voltage - Input: 9V ~ 36V
  • Voltage - Output: 15V
  • Current - Output (Max): 700mA
  • Efficiency: 89%
  • Application: ITE (Commercial)
  • ECCN: EAR99
  • Product Status: Active
  • Mounting Type: Through Hole
  • Packaging: Tube
