MSD7342-682MLC Coilcraft MSD7342-682MLC real image3657
Same model may have multiple batches, images only for reference.
MSD7342-682MLC Coilcraft MSD7342-682MLC real image3657
MSD7342-682MLC Coilcraft MSD7342-682MLC real image3657
Same model may have multiple batches, images only for reference.

MSD7342-682MLC

Part No MSD7342-682MLC
Manufacturer Coilcraft
Catalog HOT - SALES and EOL Components (M)
Description Coupled Inductors - MSD7342
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Coilcraft
Win Source Part Number 241371-MSD7342-682MLC
Popularity Medium
Supply and Demand Status Limited
Package Tape & Reel (TR)
Product Status Active
Number of Lines 2
Inductance @ Frequency 6.8 µH @ 100 kHz
Current Rating (Max) 2.1A
DC Resistance (DCR) (Max) 70 mOhm
Operating Temperature -40°C ~ 85°C
Ratings AEC-Q200
Grade -
Mounting Type Surface Mount
Size / Dimension 0.295" L x 0.295" W (7.50mm x 7.50mm)
Height (Max) 0.181" (4.60mm)
Package / Case Nonstandard
Ultra Librarian 3D Model Ultra Librarian MSD7342-682MLC CAD Model

Description

The 241371-MSD7342-682MLC is a medium-popularity inductor manufactured by Coilcraft.

  • Supply and Demand Status: Limited
  • Nominal Inductance: 680 µH
  • Maximum DC Resistance: 0.35 Ohms
  • Suitable for: Use in various applications such as power supplies, DC-DC converters, and filtering circuits
